Military

Product Detail

• 50 MHz to 1.5 GHz RF Output Frequency range
• Upconverter provides superior MER and Shoulders
• SFN and MFN support
• Linear and Non-linear Pre-correction
• GbE Transport Stream Input based on Pro-MPEG CoP #3
• WEB GUI, SNMP, Telnet remote control and software upgrade
• Available in both enclosed and board version

• Up to eight 10 MHz Outputs
• Up to eight 1pps Outputs • Optional RS232 TOD output for CMMB applications
• High performance design, utilizing an ovenized quartz oscillator
• Antenna cable length compensation
• Serial port for local console interface
• PC GUI control software available for GPR2100, GPR2110 and GPR2120
• WEB GUI and SNMP control over Ethernet for GPR1100

Click Here for Datasheet

Medical Application RF Generator

Product Detail

· Avionics waveform generation
· SDR instrumentation
· Medical/industrial RF drivers
· Lab prototyping

Wideband RF Coverage: 800 MHz to 1800MHz.
· Independent TX/RX with 12-bit ADC/DAC converters up to 61.44 MSPS
· Configurable Bandwidth: 200 kHz to 56 MHz per channel.
· High-Stability Reference: 80 MHz low-jitter XO, ±10 ppm typical
· Fractional-N PLL with optional divider and low-pass post-filter
· Clock buffer with <50 fs additive jitter and <25 ps skew
· Single +28 V DC input with on-board DC/DC and low-noise LDO regulation
· Programmable Gain Control with 90 dB dynamic range 0.25 dB steps
· TX monitor and RF power monitor ports
· Control Interfaces: SPI, I²C, RS-232, RS-485; external sync input/output
· Fan control, PSU monitoring, HPA/driver interlock and fault reporting
· Compact Integration: Designed for direct coupling to FPGA/SoC carrier

• DVB-ASI-to-IP and IP-to-DVB-ASI modes of operation
• Forward Error Correction support according to Pro-MPEG Forum CoP #3
• SFN Network preservation (SFN over IP)
• Internal or external 10 MHz reference clock and drift correction
• Low induced PCR jitter
• Low processing latency
• Protection against IP network jitter
• Configurable input buffer size for IP packets
• Front Panel, Web GUI, Telnet, CLI and SNMP support
• Remote upgrade support
• Available in both enclosed and board version

Product Detail

Medical Programmable Waveform Generator

GPS Receiver

· Avionics waveform generation
· SDR instrumentation
· Medical/industrial RF drivers
· Lab prototyping

· Wideband RF Coverage: 325 MHz to 3800 MHz
·Multi-Channel Support: 2 TX and 2 RX complex (I/Q) channels
· Instantaneous Bandwidth: Up to 20 MHz per channel.
· Synchronized Receive: Dual RX channels operate in phase coherence for accurate calibration and RF level measurement
· Independent TX/RX LO Control
· Baseband Processing: Xilinx Zynq SoC with FPGA design implementing 4 DMA channels (2 TX, 2 RX)
· Agile Operation: Supports pulse-mode transmission and real-time waveform agility.
· Automatic Level Control: Constant I/Q sample-based RF generation with fine-tune ALC adjustments
· Motor Control Subsystem: TI DRV8711 for pump drive, RPM feedback via optical encoder, and interlock safety sensor.
· Power Input: 28 - 36 V DC source with on-board conversion to 24 V for motor and regulated logic rails.
· FPGA Interface: High-density LVDS data lanes and control signals for seamless SoC integration.

OEM DVB-ASI-to-IP Bridge

Click Here for Datasheet

Programmable Waveform Generator

OEM Universal Modulator
