Termination
(Low Power)
Series No: 132
Part Description
UBS’ standard precision low-power terminations product line uses spear load elements for optimum electrical performance. Maximum power handling capacity: 0.5 watts for waveguide sizes WR-28 to WR-42, 1 watt for WR- 51 and WR-62, and 2 watts for waveguide sizesWR-75 to WR-650.
UBS’ standard precision low-power terminations product line uses spear load elements for optimum electrical performance. Maximum power handling capacity: 0.5 watts for waveguide sizes WR-28 to WR-42, 1 watt for WR- 51 and WR-62, and 2 watts for waveguide sizesWR-75 to WR-650.
