Loop Coupler
Series No: 147
Part Description
UBS series of waveguide loop couplers offers a new dimension in high directivity couplers. They are available over a coupling range of 30-70 dB. These couplers are engineered to perform with a minimum of waveguide length making them the smallest of any waveguide couplers available.
UBS series of waveguide loop couplers offers a new dimension in high directivity couplers. They are available over a coupling range of 30-70 dB. These couplers are engineered to perform with a minimum of waveguide length making them the smallest of any waveguide couplers available.
